· This filter is manufactured with fibre-glass and polyester resin. · Totally anticorrosive. · Lid of Ø 400 mm. · Supplied with manual air relief valve and water purge, sand dump port and pressure gauge panel. · Fitted with collector arms and diffuser made from unplasticised PVC and polypropilene. · Resistant to salt water. · It contains newly designed larger and more resistant ABS collector arms. · Filter bed height 1m. · Maximum temperature: 50º C. · Maximum pressure of either 2,5 or 4 Kg/cm2. OPTIONS: - Battery valves built entirely in PVC/PN-10 with flange connections to filters according to DIN standards. Butterfly and ball valves are in PVC. - Valve battery supports: made from zinc-plated steel tube, with anti-vibrations arms and fixing screw. Options for vertical and wall support.
| 00687 | 2,5 kg/cm² - Ø 1.050 - 17 m³/h |
| 00688 | 2,5 kg/cm² - Ø 1.200 - 22-33 m³/h |
| 00689 | 2,5 kg/cm² - Ø 1.400 - 30 m³/h |
| 00690 | 2,5 kg/cm² - Ø 1.600 - 40 m³/h |
| 00691 | 2,5 kg/cm² - Ø 1.800 - 50 m³/h |
| 00692 | 2,5 kg/cm² - Ø 2.000 - 62 m³/h |
| 00693 | 2,5 kg/cm² - Ø 2.350 - 87 m³/h |
| 00694 | 2,5 kg/cm² - Ø 1.050 - 25-34 m³/h |
| 00696 | 2,5 kg/cm² - Ø 1.400 - 46 m³/h |
| 00697 | 2,5 kg/cm² - Ø 1.630 - 60-80 m³/h |
| 00698 | 2,5 kg/cm² - Ø 1.800 - 76 m³/h |
| 00699 | 2,5 kg/cm² - Ø 2.000 - 94 m³/h |
| 00700 | 2,5 kg/cm² - Ø 2.350 - 130 m³/h |
| 00702 | 2,5 kg/cm² - Ø 1.200 - 45 m³/h |
| 00703 | 2,5 kg/cm² - Ø 1.400 - 61 m³/h |
| 00705 | 2,5 kg/cm² - Ø 1.800 - 101 m³/h |
| 00706 | 2,5 kg/cm² - Ø 2.000 - 125 m³/h |
| 00712 | 4 kg/cm² - Ø 1.050 - 25-34 m³/h |
| 00713 | 4 kg/cm² - Ø 1.200 - 22-33 m³/h |
| 00714 | 4 kg/cm² - Ø 1.400 - 46 m³/h |
| 00715 | 4 kg/cm² - Ø 1.600 - 60-80 m³/h |
| 00716 | 4 kg/cm² - Ø 1.800 - 76 m³/h |
| 00717 | 4 kg/cm² - Ø 2.000 - 94 m³/h |
| 00719 | 4 kg/cm² - Ø 1.200 - 45 m³/h |
| 00720 | 4 kg/cm² - Ø 1.400 - 61 m³/h |
| 00722 | 4 kg/cm² - Ø 1.800 - 101 m³/h |
| 00723 | 4 kg/cm² - Ø 2.000 - 125 m³/h |
| 04935 | 2,5 kg/cm² - Ø 2.350 - 175 m³/h |
| 08695 | 2,5 kg/cm² - Ø 2.500 - 100 m³/h |
| 08696 | 2,5 kg/cm² - Ø 2.500 - 150 m³/h |
| 08697 | 2,5 kg/cm² - Ø 2.500 - 200 m³/h |
| 08699 | 2,5 kg/cm² - Ø 3.000 - 140 m³/h |
| 08700 | 2,5 kg/cm² - Ø 3.000 - 212 m³/h |
| 08701 | 2,5 kg/cm² - Ø 3.000 - 282 m³/h |
| 09209 | 4 kg/cm² - Ø 1.050 - 17 m³/h |
| 09210 | 4 kg/cm² - Ø 1.400 - 30 m³/h |
| 09211 | 4 kg/cm² - Ø 1.600 - 40 m³/h |
| 09212 | 4 kg/cm² - Ø 1.800 - 50 m³/h |
| 09213 | 4 kg/cm² - Ø 2.000 - 62 m³/h |
| 09214 | 4 kg/cm² - Ø 2.350 - 87 m³/h |
| 09215 | 4 kg/cm² - Ø 2.500 - 100 m³/h |
| 09216 | 4 kg/cm² - Ø 3.000 - 140 m³/h |
| 09217 | 4 kg/cm² - Ø 2.350 - 130 m³/h |
| 09218 | 4 kg/cm² - Ø 2.500 - 150 m³/h |
| 09219 | 4 kg/cm² - Ø 3.000 - 212 m³/h |
| 09220 | 4 kg/cm² - Ø 2.350 - 175 m³/h |
| 09221 | 4 kg/cm² - Ø 2.500 - 200 m³/h |
| 09222 | 4 kg/cm² - Ø 3.000 - 282 m³/h |
| 00707 | 2,5 kg/cm² - Ø 1.050 – 43 m³/h |
| 00710 | 2,5 kg/cm² - Ø 1.600 – 100 m³/h |
| 00711 | 2,5 kg/cm² - Ø 1.800 – 125 m³/h |
| 33312 | 2,5 kg/cm2 - Ø 1.800 – 125 m3/h |
| 05083 | 2,5 kg/cm² - Ø 2.000 – 157 m³/h |
| 56937 | 2,5 kg/cm² - Ø 2.200 – 114 m³/h |
| 56938 | 2,5 kg/cm² - Ø 2.200 – 152 m³/h |
| 00724 | 2,5 kg/cm² - Ø 1.050 – 43 m³/h |
| 00727 | 2,5 kg/cm² - Ø 1.600 – 100 m³/h |
| 00728 | 2,5 kg/cm² - Ø 1.800 – 125 m³/h |
| 05132 | 2,5 kg/cm² - Ø 2.000 – 157 m³/h |
| 57812 | 2,5 kg/cm² - Ø 2.200 – 114 m³/h |
| 57813 | 2,5 kg/cm² - Ø 2.200 – 152 m³/h |
