DAB NKVE 32-45-65-95

DAB NKVE 32, 45, 65, 95 are multi-impeller vertical centrifugal pumps with MCE-P inverter. Designed for pressurization in civil, commercial, agricultural and watering systems. Features IE3 high energy efficiency motors and cataphoretic paint coated cast iron pump body. Operating range: 1 m³/h to 120 m³/h, head up to 320 m Pumped liquid: Clean, non-viscous, non-aggressive, non-crystallised Max glycol: 30% Liquid temperature: -30°C to +120°C (EPDM), -15°C to +120°C (Viton/FKM) Protection class: IP 55 Insulation class: F Impeller material: AISI 304 stainless steel (AISI 316 optional) Installation: Vertical
